Tips Set – For Indexable Lathe Tools 9 Piece 16mm

Tips for Indexable Lathe Tools – 9 Piece 16mm

Full sets of indexable lathe tool tips.

• For our 9 piece indexable lathe tools in 16mm size.

• Tip sets include 8 pieces, one for each tool.

• Ideal as spares or to replace worn out tips.

• TIN (carbide titanium nitride) coated for super long lasting use.

Notes for tip type

• Two different types of tips are available for 16mm 9 piece tools, both current spec and previous version

• Suitable tips for the sets currently sold are the default option above – so if you’re buying tools today you can go ahead with those.

Need tips for an older set of tools, or not sure which type you require? More details below

• 9117 set (new type, as shown here) – compatible tips are Item No. 9117A

• 9117A tips : 16ERAG60 (x2), MGEHR1616H03 (MGMN300), SCMT09T304 (x4), WCMT06T304 (x2)

• 8948 set (old type, now discontinued) – compatible tips are Item No. 8948ANEW

If you don’t have an item number for your tools and need help identifying type you have:

• 9117 new type tools – are supplied in a metal case (all 2017+ purchases).

• 8948 old type tools – were supplied in a wooden case (pre-2017 purchases).



Types available

Tool size	To fit set (Item No.)	Tool set came in	Date set bought	Tip set (Item No.)
16mm	9117	Metal packaging	2017 onwards	9117A : 16ERAG60 (x2), MGEHR1616H03 (MGMN300), SCMT09T304 (x4), WCMT06T304 (x2)
16mm	8948	Wooden packaging	Before 2017	8948ANEW

You can select the type required from the drop down menu above.



Other tips available to fit the current (9117) 16mm 9 piece tools

• Replacement parting off tips

• Replacement threading tips
